Product Description
This trolley mounted type Welding Column Boom is reckoned for its 3000 mm vertical stroke and 3000 mm horizontal stroke delivering capacity. Its horizontal speed is controlled by VFD drive and its vertical travelling direction is managed by fixed speed based mechanism. Turning rolls loading performance depends on specific type of application. Boom of this system can be availed in adjustable or fixed type design. Control section of this machine adopts digital control mechanism. Upward/downward stroke, rotational angle of column and load enduring capacity of this machine depends on application type. We are a renowned supplier and manufacturer of Welding Column Boom.
Features:
WELDING COLUMN BOOM -CBL(T)-3030
TROLLEY MOUNTED TYPE
MODEL- CBL(T)-3030
VERTICAL STROKE- 3000 MM
HORIZONTAL STROKE- 3000 MM
VERTICAL TRAVEL & TROLLEY TRAVEL - FIXED SPEED
HORIZONTAL SPEED - THROUGH VFD
CUSTOMER - RD THERM NASIK
High-Performance Welding AutomationDesigned for industrial-scale operations, this Welding Column Boom supports both manual and automatic welding modes. It delivers precise and high-quality welds, even on large or complex workpieces, with adjustable parameters to cater to varying requirements. Featuring a powder-coated mild steel build, it combines durability with aesthetic appeal for demanding environments.
Flexible and Safe OperationWith multiple mounting optionsfloor fixed or rails mountedand up to 6-meter reach, this column boom adapts to diverse working spaces. Safety is a priority; motorized height adjustment with safety locks, overload protection, and an emergency stop ensure secure operation. The digital control panel further enhances user convenience and procedural control.
Customizable to Your ApplicationAvailable with customized dimensions and capable of handling up to 5 tons, this equipment supports a wide range of welding needs. Its adjustable output voltage, low power consumption, and compatibility with various pipe or vessel diameters (up to 3 meters) make it a versatile choice for manufacturers, exporters, and suppliers across India.
FAQs of WELDING COLUMN BOOM:
Q: How does the Welding Column Boom ensure precise torch positioning during welding?
A: The equipment features a fine adjustment mechanism and a swivel head for the torch, enabling accurate positioning and adjustment during welding processes. This level of precision is critical for achieving consistent, high-quality weld seams, especially on large or irregular workpieces.
Q: What types of welding applications can this Welding Column Boom handle?
A: This machine is designed mainly for heavy structural welding, pipe welding, and vessel welding. With adjustable current (50-1000A) and capacity to accommodate up to 5 tons, it is suitable for most industrial welding automation requirements, including large-diameter projects up to 3 meters.
Q: When is it advisable to use the rail-mounted option for the base?
A: The rail-mounted base is recommended when you need to move the column boom along a larger workspace or to service multiple welding stations. If your application is fixed in one location, the floor-fixed mounting provides stable and secure operation.
Q: Where can this Welding Column Boom be installed and utilized most effectively?
A: It is best suited for large-scale fabrication environments, such as heavy machinery manufacturing units, shipyards, and workshops dealing with pipes or vessels. Its customizable dimensions and various mounting options allow for flexible installation on the shop floor.
Q: What is the operating process for this Welding Column Boom?
A: Operation begins with setting up the workpiece and configuring the digital control panel for desired weld parameters. Motorized height and torch adjustments follow, ensuring correct alignment. Welding can then proceed automatically or manually, with integrated overload and emergency stop features ensuring safety throughout the process.
Q: How does the digital control panel improve the usability of this equipment?
A: The digital control panel allows operators to manage welding parameters, travel speeds, and adjustment controls with high accuracy. This streamlines process setup, minimizes errors, and enhances productivity through intuitive interface and real-time monitoring.
Q: What benefits does this Welding Column Boom offer to manufacturers and end-users?
A: Benefits include improved welding quality, increased efficiency, and enhanced safety. The equipments versatility, robust construction, and customizable features make it a reliable investment for manufacturers seeking to automate heavy welding tasks, minimize downtime, and maintain consistent production standards.
